Automatic Tape and Reel Machine for SMD Packaging
Reliable | Accurate | Flexible — Designed for High-Yield, Low-Downtime Operation
What Is Tape and Reel Packaging for SMD devices?
Tape and reel is the standard method for preparing SMD components for automatic pick-and-place systems. The components are individually placed into embossed carrier tape pockets and sealed with a cover tape—either heat-sealed or PSA-sealed. The loaded tape is then wound onto a reel for automated assembly lines.
Our SMD taping machines are built to deliver consistent performance with minimal downtime. Whether you’re packaging 0402 resistors, QFN ICs, or other surface-mount devices. Our tape and reel solutions ensure every part is properly aligned, inspected, and sealed. Available with CCD inspection, electrical testing and defective removal options.
Solutions for a broad range of tape and reel challenges
Designed for all common SMD packages: 0402, 0603, 0805, 1206, SOP, QFN, TO252, SOP, TSSOP, DFN, etc. Our machine handles bulk, tray, and tube input formats and supports flexible EIA-compliant carrier tape widths from 8mm to 56mm.
SMD taping operation flow diagram
Feeding →Component Placement →CCD Inspection →Cover Tape Sealing →Reel Collection
Flexible Input and Output Options
- Supports bulk, tube, and tray, belt input formats
- Handles custom and standard carrier tapes
- Output on all sizes of reels, tray, tubes, or belts
Our Taping Machine Capabilities & Specifications
Built for Stability, Designed for Precision
| Spec | Value |
|---|---|
| Input Format | Bulk, Reel, Tube, Tray, Belt |
| Output Format | Tape, Tray, Tube, Belt |
| Supported Tapes | 8mm to 72mm |
| Cover Tape | Heat Seal or PSA |
| Max Speed | Up to 50K UPH (Dependent on Devices and Setup) |
| CCD Inspection | Optional |
| Electrical testing | Optional |
| Control System | PLC controller |
| Display | HMI touchscreen |
| Reel Size | 7″, 13″, 15″, 22″, plastic reels or cardboard reels |
| Parts Counter | Included |
